A2330E Ch= 19A20

A2330E Ch= 19A20; Zenith Radio Corp.; (ID = 2467841) Television
A2330E Ch= 19A20; Zenith Radio Corp.; (ID = 2469441) Television
Use red slider bar for more.
A2330E Ch= 19A20; Zenith Radio Corp.; (ID = 2469441) Television
Zenith Radio Corp.;: A2330E Ch= 19A20 [Television] ID = 2469441 486x444
Select picture or schematic to display from thumbnails on the right and click for download.
For model A2330E Ch= 19A20, Zenith Radio Corp.; Chicago, IL:
Copy from Zenith folder.

Country:  United States of America (USA)
Manufacturer / Brand:  Zenith Radio Corp.; Chicago, IL
alternative name

Chicago Radio Lab
Year: 1957 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 16: 6BZ6 6BZ6 6BZ6 6CX8 6AU6A 6BN6 6BQ5 6BY6 6CG7 6BX7 5AU4 6CN7 6CG7 6DQ6A 1B3GT 21CXP4 or 24AJP4
Main principle Superhet with RF-stage
Details
Power type and voltage Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: A2330E Ch= 19A20 - Zenith Radio Corp.; Chicago,
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 377 Folder 19-S dated 11-57)
