RA12 (12-39)

RA12 ; Zerdik; Wien (ID = 280488) Radio
RA12 ; Zerdik; Wien (ID = 3464) Radio RA12 ; Zerdik; Wien (ID = 405202) Radio
RA12 ; Zerdik; Wien (ID = 405201) Radio RA12 ; Zerdik; Wien (ID = 73063) Radio
RA12 ; Zerdik; Wien (ID = 405199) Radio RA12 ; Zerdik; Wien (ID = 405200) Radio
RA12 ; Zerdik; Wien (ID = 1066187) Radio RA12 ; Zerdik; Wien (ID = 1066190) Radio
RA12 ; Zerdik; Wien (ID = 1066191) Radio RA12 ; Zerdik; Wien (ID = 1066192) Radio
Use red slider bar for more.
RA12 ; Zerdik; Wien (ID = 3464) Radio
Zerdik; Wien: RA12 [Radio] ID = 3464 660x470
Select picture or schematic to display from thumbnails on the right and click for download.
For model RA12 (12-39), Zerdik; Wien:
Zerdik RA12

Country:  Austria
Manufacturer / Brand:  Zerdik; Wien
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: EK2 EF9 EBL1 AZ1
Main principle Super-Heterodyne (Super in general); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110 - 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: RA12 - Zerdik; Wien
Material Bakelite case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 485 x 305 x 230 mm / 19.1 x 12 x 9.1 inch
Notes .
Price in first year of sale 190.00 RM
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange + Schenk
