For model Selectric ZW318, Zerdik; Wien:
Zerdik ZW318

Country:  Austria
Manufacturer / Brand:  Zerdik; Wien
Year: 1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: EK2 EF5 EBL1 AZ1
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Selectric ZW318 - Zerdik; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Mit Sparschaltung.
Price in first year of sale 230.00 RM
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) -- Original-techn. papers.
