CB-Preamp P27M

CB-Preamp P27M; Zetagi S.p.A.; (ID = 1905650) Citizen
CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655363) Citizen CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655364) Citizen
CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655365) Citizen CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655366) Citizen
CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655367) Citizen CB-Preamp P27M; Zetagi S.p.A.; (ID = 1916053) Citizen
Use red slider bar for more.
CB-Preamp P27M; Zetagi S.p.A.; (ID = 1655363) Citizen
Zetagi S.p.A.;: CB-Preamp P27M [Citizen] ID = 1655363 733x550
Select picture or schematic to display from thumbnails on the right and click for download.
For model CB-Preamp P27M, Zetagi S.p.A.; Concorezzo, Milano

Country:  Italy
Manufacturer / Brand:  Zetagi S.p.A.; Concorezzo, Milano
Brand

ZG
Year: 1980 ? Category: Citizen Band Equipment
Semiconductors (the count is only for transistors) 3:
Main principle Radio Frequency Amplification only
Wave bands Short Wave (SW only)
Details
Power type and voltage Storage and/or dry batteries / 10-15 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: CB-Preamp P27M - Zetagi S.p.A.; Concorezzo,
Material Metal case
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 43 x 45 x 110 mm / 1.7 x 1.8 x 4.3 inch
Notes
CB-Preamplificatore P27M d'antenna
Caratteristiche tecniche:
Frequenza: 26-30 MHz
Guadagno: 25 dB regolabile
Alimentazione: 10-15 Vcc
Assorbimento: 100 mA
Potenza max. applicabile: 50 Watt AM


Net weight (2.2 lb = 1 kg) 0.220 kg / 0 lb 7.8 oz (0.485 lb)

Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
