Zvezda {Звезда} [Red Star] 54; ZH-68; Moscow. (ID = 88352) Radio
ZH-68; Moscow.: Zvezda {Звезда} [Red Star] 54 [Radio] ID = 88352 624x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Zvezda {Звезда} [Red Star] 54 horizontal chassis, ZH-68; Moscow.:
horizontal (clasic) shassis

Country:  Soviet Union
Manufacturer / Brand:  ZH-68; Moscow.
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6А7 6Ж3П or 6К4П 6Х2П 6Ж3П 6Е5С 6П1П 6Ц4П
Main principle Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 127; 220 Volt
Loudspeaker 2 Loudspeakers / Ø 14 cm = 5.5 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Zvezda {Звезда} [Red Star] 54 [horizontal chassis] - ZH-68; Moscow.
Material Metal case
Shape Design Radio or Novelty / Gadget - fancy or unusual shape.
Dimensions (WHD) 530 x 320 x 180 mm / 20.9 x 12.6 x 7.1 inch
Notes Radio set "Zvezda-54" at first made in Charkov "Komunar" Works, USSR (1954) and after modernize in "ZH-68" Works (secret subsidiary MEMZ Nr. 1 factory, Moscow, 1955). USSR. The prototype was the French radio set SNR "Excelsior 52". Radio cabinet colourable red, green or blue. But generally color - red (and got name "Red Star").
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Literature/Schematics (1) E.A.Levitin, Radiovescatelnyje prijomniki, Moscow 1960

Model page created by Zenonas Langaitis. See "Data change" for further contributors.
