Oktava {Октава} radiogramophone; Lenin Radio Works, (ID = 109119) Radio
Lenin Radio Works,: Oktava {Октава} radiogramophone [Radio] ID = 109119 667x519
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oktava {Октава} radiogramophone, Lenin Radio Works, Gorky:
Kaunas, Lithuania

Country:  Soviet Union
Manufacturer / Brand:  Lenin Radio Works, Gorky
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6Н3П 6И1П 6К4П 6Х2П 6Е5С 6Н2П 6П14П
Main principle Super-Heterodyne (Super in general); ZF/IF 465 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220 Volt
Loudspeaker 4 Loudspeakers
Power out 6 W (unknown quality)
from Radiomuseum.org Model: Oktava {Октава} radiogramophone - Lenin Radio Works, Gorky
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 580 x 406 x 330 mm / 22.8 x 16 x 13 inch
Notes Loudspeakers 2x2W and 2x1W. Record player 33 and 78 rpm, piezoelectric tone-arm model ZPK-55M.
FM 64,5-73,5 MHz.
Net weight (2.2 lb = 1 kg) 19 kg / 41 lb 13.6 oz (41.85 lb)
Mentioned in E.A. Levitin, "Spravocnik po radiovesciatelnim prijomnikam", Moscow 1960

Model page created by Zenonas Langaitis. See "Data change" for further contributors.
