2N217

Information - Help
ID = 35364

Country:
United States of America (USA)
Brand: Common type USA tube/semicond.
Tube type:  Transistor   Audio Frequency
Identical to 2N217
Similar Tubes
Normally replaceable-slightly different:
  10037 ; 2N104 ; 2N17 ; 2S37 ; 2S44 ; 353 ; AC122 ; DS-14 ; DS-16 ; HJ-17 ; HJ-17D ; HJ17D ; OC604 ; TI353 ; TJ-35
Other base and data slightly different:
  CK882 ; CK888
Multiple differences or of other kind:
  2N42
First Source (s)
Mar.1957 : -- Collector info (Sammler)
Predecessor Tubes 2N104
Base Wires
Description

PNP germanium alloy transistor intended as AF amplifier.
-


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip		 6 x 10 x mm / 0.24 x 0.39 x inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   KTT 1969/70
2N217: RCA Transistor Manual
Heinz Höger
to_1_ttt~~5.gif 2N217: TTT Steidle 1981
Günther Stabe † 19.8.20
2N217: Amperex Manual 1958
Heinz Höger
More ...
Usage in Models 1= 1956? ; 11= 1957? ; 1= 1957 ; 5= 1958? ; 12= 1958 ; 3= 1959?? ; 15= 1959? ; 18= 1959 ; 4= 1960?? ; 5= 1960? ; 13= 1960 ; 2= 1961?? ; 3= 1961? ; 9= 1961 ; 1= 1962?? ; 1= 1962? ; 1= 1962 ; 3= 1963?? ; 10= 1963 ; 1= 1964? ; 9= 1964 ; 3= 1965?? ; 1= 1965 ; 3= 1966 ; 2= 1968?? ; 1= 9999? ; 8= 9999
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):146
