2N5457

Information - Help
ID = 46601

Country:
United States of America (USA)
Brand: Common type USA tube/semicond.
Tube type:  Transistor   Universal
Identical to 2N5457
Similar Tubes
Normally replaceable-slightly different:
  2N3823 ; 2N5459 ; BF244 ; BF245
Other base and data slightly different:
  2N4302

Base Wires
Filament Solid State
Description

Silicon N-channel junction FET for universal purpose.
-


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
6 x 5 x 5 mm / 0.24 x 0.20 x 0.20 inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   TTT Steidle 1981
  2N5457: Personal file
Antonio Rabitti

2N5457: TVT 1969 Verlag Nolde Dachau
Günther Stabe † 19.8.20


2N5457: Siliconix-FET 1979
Heinz Höger


Usage in Models 1= 1969 ; 1= 1971?? ; 1= 1974

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):3
