6N8P

Information - Help
ID = 46963

Country:
People's Republic of China
Brand: Common type China (PRC) tube/semicond.
Tube type:  Double Triode
Identical to 6N8P
Similar Tubes
Normally replaceable-slightly different:
  6SN7GT ; 6Н8С

Base Octal (Int.Octal, IO) K8A, USA 1935
Filament Vf 6.3 Volts / If 0.6 Ampere / Indirect / Parallel / series AC/DC
Description General purpose dual triode, similar to 6SN7GT.
Literature - - Manufacturers Literature
- - -
- - -
- - -
  6N8P: From my personal documents
Christian Walldorf

6N8P: Personal Collection of CHRISTIAN WALLDORF
Christian Walldorf


6N8P: Manufacturer's Literature
Emilio Ciardiello


6N8P: Manufacturer's Literature
Emilio Ciardiello


Usage in Models 1= 2003?? ; 1= 2009?

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):2
