BU2302

Information - Help
ID = 68642

Country:
Japan
Brand: ROHM Co., Ltd.; Kyoto
Tube type:  IC - Integrated Circuit
Identical to BU2302
Similar Tubes
Other characteristic (electr. data):
  BU2305

Base SPECIAL TUBEBASE in general
Description

Aufbau/Content: IC (CMOS);
Form/Case/Outline: DIP-8 (BU2302) | SOP-8 (BU2302F);
Applikation/Type: Single RC Type Timer;
Daten/electr.data: Vdd: 3 V (1.8 ... 6 V); Iddq: <0.5 µA; Pd: <500 mW; f osc: 1.17 kHz; t op: -20...+75 °C.
-


Dimensions (WHD)
incl. pins / tip
10 x 7 x 8 mm / 0.39 x 0.28 x 0.31 inch
Weight 1 g / 0.04 oz
Information source -- Original-techn. papers.

BU2302: ROHM
Günther Stabe † 19.8.20
    More ...
dip_8~~66.png BU2302: TTT Steidle 1981
Günther Stabe † 19.8.20

BU2302: ROHM
Günther Stabe † 19.8.20

Usage in Models 1= 1990 ; 1= 1992

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):2
