CA3161
|
Country:
United States of America (USA)
|
|
| Identical to |
CA3161
|
| Base |
SPECIAL TUBEBASE in general
|
| Description |
Aufbau/Content: IC (__ Trans., __ Widerst., __ Dioden, __ Kond.);
Form/Case/Outline: DIP-16 (CA3161[E]);
Type/Application: BCD to Seven Segment Decoder/Driver;
Daten/electr.data: Vcc: 5 V; Icc: 3.5 / 25 mA; Pd: <1 W (18 mW standby); t op: 0...75 °C.
-
|
Dimensions (WHD)
incl. pins / tip |
20 x 7 x 8 mm / 0.79 x 0.28 x 0.31 inch |
| Weight |
1 g / 0.04 oz |
| Information source |
- - Manufacturers Literature
|
CA3161: InterSil
Günther Stabe † 19.8.20
|
CA3161: RCA
Günther Stabe † 19.8.20
|
|
CA3161: RCA
Günther Stabe † 19.8.20
|
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):4
