GA102

Information - Help
ID = 46176

Country:
Germany
Brand: Halbleiterwerk Frankfurt /Oder, VEB, (HFO); Frankfurt /Oder (Ostd.)
Developer: Werk für Bauelemente der Nachrichtentechnik (WBN), Teltow, VEB, RFT (Ostd.) - vorm. DRALOWID
Tube type:  Solid-State-Diode   Detector
Identical to GA102
Similar Tubes
Other shape (e.g. bulb type):
  OA665
Normally replaceable-slightly different:
  Д9
Predecessor Tubes OA665

Base Wires
Filament Solid State
Description Material/Aufbau: Germanium Punktkontakt;
Form/Case: (axial);
Daten/electr.data: I F: 3 mA; U F: 1 V; I sp: 40 µA; U sp: 10 V; Imax: 12 mA; Umax: 60 V; tmax: 60 °C.
Ge-Universaldiode für Hochfrequenz -
Dimensions (WHD)
incl. pins / tip
8 x 3 x mm / 0.31 x 0.12 x inch
Weight 1 g / 0.04 oz
Information source -- Collector info (Sammler)   Radio und Fernsehen H.6/1966
- - -
- - -
- - -
  GA102: electronica 126 S.29
Egon Strampe

GA102: W.E.
Wolfgang Eckardt


GA102: DVT 1971 ECA
Günther Stabe † 19.8.20
