GC10D

Information - Help
ID = 27934



Tube type:  Dekatron
Identical to GC10D
Similar Tubes
Normally replaceable-slightly different:
  CV5143

Base Octal (Int.Octal, IO) K8A, USA 1935
Filament
Description

Faster version of the GC10B, counting to 20k pulses per second.

The tube differs from the GC10B in that it has an additional set of guide pins above the two sets of the GC10B.


Information source - - Manufacturers Literature

GC10D: Ericsson Datenbuch, Ausgabe 2, März 1961
Achim Dassow

gc10d_socket.gif GC10D: AD
Achim Dassow


Just Qvigstad
GC10D: Ericsson Datenbuch, Ausgabe 2, März 1961
Achim Dassow

More ...
Usage in Models 1= 1962

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):1
