HA13151

Information - Help
ID = 78563

Country:
Japan
Brand: Hitachi Ltd.; Tokyo
Tube type:  IC - Integrated Circuit   Power/Output
Identical to HA13151

Base Wires
Description

Aufbau/Content: IC (__ Trans., __ Widerst., __ Dioden, __ Kond.);
Form/Case/Outline: ZIP-23-K;
Type/Application: 14 W x 4-Channel BTL Power IC @ 4 Ω (14.4 V);
Daten/electr.data: Vcc: 13.2 V; Iccq: 270 mA; Io (peak): 3 A; Rin: 25 kΩ; THD: 0.05 %; Pt: <83 W; Gain: 32 dB; t op: -30...+85 °C;
-


Dimensions (WHD)
incl. pins / tip
30 x 17 x 5 mm / 1.18 x 0.67 x 0.20 inch
Weight 3 g / 0.11 oz
Information source - - Manufacturers Literature

HA13151: Hitachi
Günther Stabe † 19.8.20

ha13150_s~~1.png HA13151: Hitachi
Günther Stabe † 19.8.20
