Aufbau/Content: IC ( __ Trans., __ Widerst., __ Kond., __ Dioden); Form/Case/Outline: TO-92 Anschlussfolge Vout-Vin-Gnd (HT7130[A]) | SOT-89; Type/Application: 3-terminal voltage regulator; HT71xx - family*; Daten/electr.data: U in: <24 V; U out: 3 V +/- 5 %; I out: <30 mA; Pd: 200 mW; t op: 0...+70 °C; *) xx = Uout: + 30 (3.0V)/33 (3.3V)/36 (3.6V)/44 (4.4V)/50 (5.0V). Ähnlich/similar: HT1030; Family: HT10xx = HT1015 (1.5V)...HT1070 (7.0V); Manufactured by HOLTEK -
