MSM82C53

Information - Help
ID = 82040

Country:
Japan
Brand: Common type Japan tube/semicond.
Tube type:  IC - Integrated Circuit
Identical to MSM82C53

Base Wires
Filament Solid State
Description

Aufbau/internal: IC (CMOS);
Form/Case/Outline: DIP-24 (MSM82C53-2RS) | QFP-28 (MSM82C53-2JS) | SSOP-32 (MSM82C53-2GS-K);
Type/Application: Programmable Interval Timer;
Daten/electr.data: Vdd: 3...6 V; Idd: <8 mA, f op: <8 MHz; Pd: <0.9 W; t op: -40...+85 °C.
Manufactured by OKI Semiconductor (J)
-


Dimensions (WHD)
incl. pins / tip
30 x 7 x 15 mm / 1.18 x 0.28 x 0.59 inch
Weight 2 g / 0.07 oz
Information source - - Manufacturers Literature
  MSM82C53: OKI
Günther Stabe † 19.8.20

MSM82C53: Sammlung Alois Wolf
Alois Wolf


MSM82C53: OKI
Günther Stabe † 19.8.20


MSM82C53: OKI
Günther Stabe † 19.8.20
