MW6-2

Information - Help
ID = 21546



Tube type:  Projection Television picture tube B/W
Identical to MW6-2
Similar Tubes
Multiple differences or of other kind:
  3NP4_CRT

Filament Vf 6.3 Volts / If 0.3 Ampere / Indirect / Parallel / series AC/DC
Description Va <25kV. Magnetic deflection and focus.
Internal spark trap.
Tube prices 1 Tube prices (visible for members only)
Literature - - Manufacturers Literature
  MW6-2: org.Doku
Franz Born †

MW6-2
Jürgen Küting


MW6-2: rtt
Michael Schlör


MW6-2: SEL Handbuch 1964
Peter Hoddow


Usage in Models 6= 1951 ; 3= 1952? ; 2= 1952 ; 1= 1954 ; 1= 1956 ; 2= 1957 ; 1= 1958? ; 1= 1958 ; 1= 1960? ; 2= 1960

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):20
