SFD108

Information - Help
ID = 38563

Country:
France
Brand: COSEM; Saint-Egrève
Tube type:  Solid-State-Diode   Universal
Identical to SFD108
Similar Tubes
Normally replaceable-slightly different:
  AA118 ; AA132 ; OA81 ; OA91

Base Wires
Filament Solid State
Description Material/Aufbau: Germanium Punktkontakt;
Form/Case/Outline: Allglas DO-7;
Daten/electr.data: I F: 5 mA; U F: 1 V; I sp: 7 µA; U sp: 10 V; Imax: 30 mA; Umax: 100 V; tmax j: 85 °C.
Variante: SFD108A = Imax: 50 mA, I F: 30 mA, t amb: 25 °C;
Dimensions (WHD)
incl. pins / tip
8 x 3 x mm / 0.31 x 0.12 x inch
Weight 1 g / 0.04 oz
Literature - - Manufacturers Literature   Thomson

SFD108: ma propre collection
Jacky Parmentier


SFD108: DVT 1971 ECA
Günther Stabe



Usage in Models 2= 1959 ; 3= 1962?? ; 1= 1962 ; 4= 1963?? ; 3= 1963 ; 13= 1964 ; 9= 1965 ; 5= 1966? ; 4= 1966 ; 2= 1967? ; 13= 1967 ; 4= 1968 ; 1= 1969?? ; 1= 1969 ; 3= 1970?? ; 2= 1971?? ; 5= 1971 ; 2= 1972? ; 1= 1972 ; 1= 1974 ; 1= 1975 ; 1= 1976?? ; 2= 1977?? ; 2= 1980??

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):85
