TA7331

Information - Help
ID = 62012

Country:
Japan
Brand: Toshiba Corporation; Tokyo
Tube type:  IC - Integrated Circuit   Power/Output
Identical to TA7331
Base Wires
Description

Aufbau/Content: IC (__ Trans., __ Widerst., __ Dioden);
Form/Case/Outline: SIL-9 (TA7331P) | SSOP-16 (TA7331F);
Type/Application: Low quiescent current audio power amplifier for mini-micro cassette tape recorder;
Daten/electr.data: Vcc: 2...5 V; Iccq: 3 mA; Voltage gain: 50 dB; THD: 1 %; Pd: <700 mW, Pout (TA7331P): 500 mW @ 4Ω (4.5 V) | 300 mW @ 8Ω (3V); Pout (TA7331F/TA7331P): 200 mW @ 4Ω (3 V) | 120 mW @ 8Ω (3V); top: -10...+60 °C.
-


Dimensions (WHD)
incl. pins / tip		 22 x 6 x 3 mm / 0.87 x 0.24 x 0.12 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature
TA7331: Toshiba
Günther Stabe † 19.8.20     More ...
sil_9~~3.gif TA7331: Toshiba
Günther Stabe † 19.8.20
More ...
TA7331: Toshiba
Günther Stabe † 19.8.20
More ...
Usage in Models 1= 1980?? ; 1= 1981? ; 1= 1982? ; 1= 1983? ; 1= 1984? ; 1= 1984 ; 1= 1990?? ; 1= 1992? ; 1= 1995??
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):9
