TDA2020

Information - Help
ID = 35461

Country:
Italy
Brand: ATES Componenti Elettronici, Milano
Tube type:  IC - Integrated Circuit   Power/Output
Identical to TDA2020 = MDA2020
Similar Tubes
Other characteristic (electr. data):
  TDA2010

Base SPECIAL TUBEBASE in general
Description

Monolithic integrated AF power amplifier max. 24 W @ 4 Ohm, <36 V.
-


Text in other languages (may differ)
Dimensions (WHD)
incl. pins / tip
19 x 8 x 6 mm / 0.75 x 0.31 x 0.24 inch
Weight 2 g / 0.07 oz
Information source - - Manufacturers Literature   SGS-ATES

TDA2020: SGS ATES datasheet
Günther Stabe † 19.8.20
    More ...
tda2020.gif TDA2020: SGS ATES datasheet
Günther Stabe † 19.8.20

TDA2020: SGS ATES datasheet
Günther Stabe † 19.8.20

More ...
Usage in Models 1= 1970?? ; 1= 1976?? ; 1= 1977?? ; 2= 1978?? ; 1= 1979 ; 1= 1987

Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):7

Collection of



TDA2020
