TDA7310

Information - Help
ID = 77375

Country:
France
Brand: Thomson (marque), Thomson-Houston (CFTH, Mazda); Paris
Tube type:  IC - Integrated Circuit   Audio Frequency
Identical to TDA7310

Base Wires
Filament Solid State
Description

Aufbau/Content: IC (Bipolar / CMOS);
Form/Case/Outline: PQFP-44;
Applikation/Type: Serial BUS controlled Audio Processor;
Daten/electr.data: Vcc: 9 V; Ptot: __ mW; Icc: 8 mA; t amb: -40...+85 °C.
Manufactured by ST - SGS Thomson
-


Dimensions (WHD)
incl. pins / tip
10 x 10 x 2 mm / 0.39 x 0.39 x 0.08 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature   SGS Thomson
  TDA7310: ST
Günther Stabe † 19.8.20

TDA7310: Eigene Sammlung
Egon Strampe


TDA7310: ST
Günther Stabe † 19.8.20


TDA7310: ST
Günther Stabe † 19.8.20
