UL1200

Information - Help
ID = 61495

Country:
Poland
Brand: Unitra CEMI, Naukowo-Produkcyjne Centrum Półprzewodników; Warschau
Tube type:  IC - Integrated Circuit   RF/IF-Stage
Identical to UL1200
Similar Tubes
Normally replaceable-slightly different:
  CA3089 ; LM3089
Base SPECIAL TUBEBASE in general
Description

Aufbau/Content: IC (__ Trans., __ Widerst., __ Dioden);
Form/Case: DIP-16 (UL1200N);
Type: FM IF Amplifier, Demodulator, Signal, AFC;
Data: Vcc: <16 V; Icc: 23 mA; Pd: 600 mW; Tj: -25 ... +70 °C;
-


Dimensions (WHD)
incl. pins / tip		 20 x 7 x 8 mm / 0.79 x 0.28 x 0.31 inch
Weight 1 g / 0.04 oz
Information source - - Manufacturers Literature
UL1200: Unitra
Günther Stabe † 19.8.20
ul1200n_s.png UL1200: Unitra
Günther Stabe † 19.8.20
UL1200: Unitra
Günther Stabe † 19.8.20
Usage in Models 1= 1982 ; 2= 1985?? ; 3= 1990?
Quantity of Models at Radiomuseum.org with this tube (valve, valves, valvola, valvole, válvula, lampe):6
