Quad I (1)

Quad I ; Acoustical (ID = 1560977) Ampl/Mixer Quad I ; Acoustical (ID = 1560979) Ampl/Mixer
Quad I ; Acoustical (ID = 1560982) Ampl/Mixer Quad I ; Acoustical (ID = 1560984) Ampl/Mixer
Quad I ; Acoustical (ID = 1560986) Ampl/Mixer Quad I ; Acoustical (ID = 1560988) Ampl/Mixer
Quad I ; Acoustical (ID = 1560990) Ampl/Mixer
Use red slider bar for more.
Quad I ; Acoustical (ID = 1560977) Ampl/Mixer
Acoustical: Quad I [Ampl/Mixer] ID = 1560977 933x685
Select picture or schematic to display from thumbnails on the right and click for download.
For model Quad I (1), Acoustical Manufacturing Co. Ltd, The; Huntingdon:
aus ebay, #190964987879, mit Erlaubnis des Verkäufers mono

Country:  Great Britain (UK)
Manufacturer / Brand:  Acoustical Manufacturing Co. Ltd, The; Huntingdon
Brand

Quad
Year: 1950 ? Category: Audio Amplifier or -mixer
Valves / Tubes 5: EF37A EF37A KT66 KT66 GZ32
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 200-210; 220-230; 240-250 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Quad I - Acoustical Manufacturing Co.
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 9.5 x 7.5 x 6.5 inch / 241 x 191 x 165 mm
Notes

QUAD (Quality Unit Amplifier Domestic) mono power amplifier, with power supply for the associated QC1 pre-amplifier (Control Unit).

Net weight (2.2 lb = 1 kg) 16.8 lb (16 lb 12.8 oz) / 7.627 kg

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
