For model Magnetophon 97, AEG (Radios) Allg.Elektricitäts-Ges.

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1961–1963 Category: Sound/Video Recorder and/or Player
Valves / Tubes 7: EF86 EF86 ECC81 ECC81 EM84 EL95 EL95
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Magnetophon 97 - AEG Radios Allg.Elektricitäts-
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 410 x 200 x 292 mm / 16.1 x 7.9 x 11.5 inch
Notes Vierspur; Mono-Aufnahme und Wiedergabe sowie Stereo-Wiedergabe; 4,75/9,5/19 cm/s. Spulen-Ø 18 cm. NF-Ausgangsleistung 2× 2,5 W.
Siehe auch: Telefunken Magnetophon 97.
Dieses Gerät ist ein Vollstereogerät, siehe Schaltplan und Beschreibung.
Net weight (2.2 lb = 1 kg) 12.4 kg / 27 lb 5 oz (27.313 lb)
Price in first year of sale 825.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1961/62
