For model Magnetophon KL25, AEG (Radios) Allg.Elektricitäts-Ges.:
D; AEG; Allg.Elektricitäts-Ges.; Magnetophon KL25

Country:  Germany
Manufacturer / Brand:  AEG (Radios) Allg.Elektricitäts-Ges.
Year: 1953–1955 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: EF804 ECC81 ECC81 EL41 EM71a
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Magnetophon KL25 - AEG Radios Allg.Elektricitäts-
Material Leather / canvas / plastic - over other material
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 425 x 325 x 185 mm / 16.7 x 12.8 x 7.3 inch
Notes Das Magnetophon KL25 von AEG ist ein Zweispurgerät für 9,5 cm/s. Das KL25 enthält eine Diktiereinrichtung mit Schnellstopp- und Kurzrücklauf für Fußtastenanschluss.
Net weight (2.2 lb = 1 kg) 13.5 kg / 29 lb 11.8 oz (29.736 lb)
Price in first year of sale 885.00 DM
Source of data HdB d.Rdf-& Ferns-GrH 1953/54 / Radiokatalog Band 1, Ernst Erb
Mentioned in HdB d.Rdf-& Ferns-GrH 1954/55
