Trägersprechgerät, Endstelle MEK 8

• Country
• Germany

• Manufacturer / Brand
• AEG (Radios) Allg.Elektricitäts-Ges.

• Year
• 1942

• Category
• Morse-Equipment & TTY, RTTY, TDD etc.

• Radiomuseum.org ID
• 234435

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• C3b C3b E2d E2d E2d Bi Bi Bi Bi STV150/15 75.7400

• Main principle
• Audio-Amplification

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 150; 220; 240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Trägersprechgerät, Endstelle MEK 8 - AEG Radios Allg.Elektricitäts-

• Shape
• Boatanchor (heavy military or commercial set >20 kg).

• Notes

• Für bis zu 8 Telefonie/Fernschreibkanäle auf Zweidrahtleitungen.

  Bis 60 kHz Trägerfrequenzbeanspruchung.



  Röhrenzahl mal Faktor 8 !

• Mentioned in
• Reichspostzentralamt Becshreibung Nr. 318 E11a 2. Ausgabe, Juli 1942

• Author
• Model page created by a member from A. See "Data change" for further contributors.

• Other Models

• Here you find 840 models, 731 with images and 417 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from AEG (Radios) Allg.Elektricitäts-Ges.
