Lilla Orkester 8508

Lilla Orkester 8508; AGA and Aga-Baltic (ID = 2590357) Radio
Use red slider bar for more.
Lilla Orkester 8508; AGA and Aga-Baltic (ID = 2590357) Radio
AGA and Aga-Baltic: Lilla Orkester 8508 [Radio] ID = 2590357 800x669
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lilla Orkester 8508, AGA and Aga-Baltic Radio AB; Sweden:
AGA brochure

Country:  Sweden
Manufacturer / Brand:  AGA and Aga-Baltic Radio AB; Sweden
alternative name

AGA-Baltic Radio AB; Stockholm
Year: 1949 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH21 UF21 UF21 UBL21 UM4 UY1N
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details Record Player (not changer)
Power type and voltage AC/DC-set
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: Lilla Orkester 8508 - AGA and Aga-Baltic Radio AB;
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes

Record player built-in.

Price in first year of sale 879.00 SEK
Mentioned in -- Original prospect or advert

Model page created by Mark Hippenstiel. See "Data change" for further contributors.
