Einschubhalterung CV647/48

Akkord-Radio + Akkord Elektronik (Radios)

  • Year
  • 1967–1969
  • Category
  • Radio module post 1925 (not a part, not a key)
  • Radiomuseum.org ID
  • 188955

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6; 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 6 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Einschubhalterung CV647/48 - Akkord-Radio + Akkord
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 185 x 50 x 130 mm / 7.3 x 2 x 5.1 inch
  • Notes
  • Autohalterung mit eingebauter Endstufe für die Akkord Radios Autotransistor automatic 640 und K641, die auch außerhalb der Konsole mit Trockenbatterien betrieben werden können. Im Auto wurde die Halterung nicht unter das Armaturenbrett, sondern mit vergrößertem Ausschnitt anstelle des normalen Autoradios eingebaut. Eine elektrisch betriebene mechanische Verriegelung verhinderte als Diebstahlschutz das Entfernen des Radios.
  • Net weight (2.2 lb = 1 kg)
  • 0.850 kg / 1 lb 14 oz (1.872 lb)
  • Price in first year of sale
  • 90.00 DM
  • Author
  • Model page created by Willi Ribbe. See "Data change" for further contributors.
