Pinguin U59c

Pinguin U59c; Akkord-Radio + (ID = 1857766) Radio

Pinguin U59c; Akkord-Radio + (ID = 1857767) Radio
Pinguin U59c; Akkord-Radio + (ID = 949259) Radio Pinguin U59c; Akkord-Radio + (ID = 949260) Radio
Pinguin U59c; Akkord-Radio + (ID = 949262) Radio Pinguin U59c; Akkord-Radio + (ID = 949263) Radio
Pinguin U59c; Akkord-Radio + (ID = 949264) Radio Pinguin U59c; Akkord-Radio + (ID = 949267) Radio
Pinguin U59c; Akkord-Radio + (ID = 949269) Radio Pinguin U59c; Akkord-Radio + (ID = 949275) Radio
Pinguin U59c; Akkord-Radio + (ID = 1299211) Radio Pinguin U59c; Akkord-Radio + (ID = 1765475) Radio
Use red slider bar for more.
Pinguin U59c; Akkord-Radio + (ID = 949259) Radio
Akkord-Radio +: Pinguin U59c [Radio] ID = 949259 835x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pinguin U59c, Akkord-Radio + Akkord Elektronik (Radios)

Country:  Germany
Manufacturer / Brand:  Akkord-Radio + Akkord Elektronik (Radios)
Year: 1959/1960 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: DF97 DK92 DF96 DF96 DF96 DAF96 DL96
Main principle Super-Heterodyne (Super in general); ZF/IF 468/10700 kHz; 1 AF stage(s)
Tuned circuits 7 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 110; 125; 155; 220; 240 / 2 x 1,5 & 100 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Pinguin U59c - Akkord-Radio + Akkord
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 217 x 120 mm / 12.4 x 8.5 x 4.7 inch
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Collectors' prices
Source of data - - Data from my own collection

Model page created by Ulrich Fieseler. See "Data change" for further contributors.



All listed radios etc. from Akkord-Radio + Akkord Elektronik (Radios)
Here you find 194 models, 172 with images and 142 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
