Pinguin U62 de Luxe Ch= 513/3600

Pinguin U62 de Luxe; Akkord-Radio + (ID = 91692) Radio

Pinguin U62 de Luxe; Akkord-Radio + (ID = 91693) Radio

Pinguin U62 de Luxe; Akkord-Radio + (ID = 91694) Radio

Pinguin U62 de Luxe; Akkord-Radio + (ID = 91695) Radio

Pinguin U62 de Luxe; Akkord-Radio + (ID = 91696) Radio
Pinguin U62 de Luxe; Akkord-Radio + (ID = 296741) Radio Pinguin U62 de Luxe; Akkord-Radio + (ID = 525173) Radio
Pinguin U62 de Luxe; Akkord-Radio + (ID = 2294844) Radio Pinguin U62 de Luxe; Akkord-Radio + (ID = 35919) Radio
Pinguin U62 de Luxe; Akkord-Radio + (ID = 35918) Radio Pinguin U62 de Luxe; Akkord-Radio + (ID = 126959) Radio
Pinguin U62 de Luxe; Akkord-Radio + (ID = 126960) Radio Pinguin U62 de Luxe; Akkord-Radio + (ID = 296742) Radio
Pinguin U62 de Luxe; Akkord-Radio + (ID = 296743) Radio Pinguin U62 de Luxe; Akkord-Radio + (ID = 296744) Radio
Use red slider bar for more.
Pinguin U62 de Luxe; Akkord-Radio + (ID = 296741) Radio
Akkord-Radio +: Pinguin U62 de Luxe [Radio] ID = 296741 808x630
Select picture or schematic to display from thumbnails on the right and click for download.
For model Pinguin U62 de Luxe Ch= 513/3600, Akkord-Radio + Akkord Elektronik (Radios)

Country:  Germany
Manufacturer / Brand:  Akkord-Radio + Akkord Elektronik (Radios)
Year: 1962/1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes E25C25 E25C5 E25C5 E37,5C5
Semiconductors (the count is only for transistors) 9: OC615 OC615 OC614 AF105a AF105 OC604 OC604 AC106 AC106 BA101 OA90 OA172 OA172
Main principle Super-Heterodyne (Super in general); ZF/IF 460/10700 kHz
Tuned circuits 7 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Pinguin U62 de Luxe [Ch= 513/3600] - Akkord-Radio + Akkord
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 200 x 115 mm / 12.2 x 7.9 x 4.5 inch
Notes Ovallautsprecher 65 x 250 mm. Koax-Antennenanschluß für Autobetrieb. Anschlüsse für Tonbandgerät und ext. Lautsprecher. Separates Netzteil möglich.
Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Price in first year of sale 326.00 DM
Collectors' prices
Source of data Handbuch VDRG 1962/1963 / Radiokatalog Band 1, Ernst Erb
