Chenonceaux (59)

Chenonceaux ; Amplix CGTVE; Paris (ID = 227784) Radio

Chenonceaux ; Amplix CGTVE; Paris (ID = 227785) Radio
Chenonceaux ; Amplix CGTVE; Paris (ID = 1675018) Radio Chenonceaux ; Amplix CGTVE; Paris (ID = 306311) Radio
Use red slider bar for more.
Chenonceaux ; Amplix CGTVE; Paris (ID = 1675018) Radio
Amplix CGTVE; Paris: Chenonceaux [Radio] ID = 1675018 600x452
Select picture or schematic to display from thumbnails on the right and click for download.
For model Chenonceaux (59), Amplix (CGTVE); Paris:
Dépliant ca. 1959

Country:  France
Manufacturer / Brand:  Amplix (CGTVE); Paris
Year: 1958–1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF89F or EF89 ECH81 EBF80 EBF80 EM85 or EM81 EL84 EZ80
Main principle Superhet with RF-stage; ZF/IF 480 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Chenonceaux - Amplix CGTVE; Paris
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 345 x 270 mm / 22 x 13.6 x 10.6 inch
Notes

4 gammes d'ondes: GO 950 à 1950 m, PO 190 à 575 m, OC 17 à 51 m, bande étalée 47 à 50,5 m. Cadre à air incorporé orientable. Prise PU et HPS.

Ébénisterie noix verni noyer et sycomore, chêne clair sur demande.

Prix pour Chenonceaux 59; en 1959 (idem): 46224 Fr., en 1961 (Chenonceaux): 46224 Fr.

Lampes selon dépliant: EF89F et EM85, selon le schéma: EF89 et EM81.

Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 44'875.00 FRF
External source of data Serge Laffont/Martin Renoth
Mentioned in -- Original prospect or advert
Literature/Schematics (1) - - Manufacturers Literature (Tarif détail 1.5.1958, 1.5.1959, 1.6.1961)

Model page created by Ernst Erb. See "Data change" for further contributors.
