Anglo-Nordic 290-FM bafle tiro tejido

Anglo-Nordic 290-FM; Anglo Española de (ID = 1533892) Radio Anglo-Nordic 290-FM; Anglo Española de (ID = 1533893) Radio
Anglo-Nordic 290-FM; Anglo Española de (ID = 1533894) Radio Anglo-Nordic 290-FM; Anglo Española de (ID = 1533895) Radio
Anglo-Nordic 290-FM; Anglo Española de (ID = 1533896) Radio Anglo-Nordic 290-FM; Anglo Española de (ID = 1533897) Radio
Use red slider bar for more.
Anglo-Nordic 290-FM; Anglo Española de (ID = 1533892) Radio
Anglo Española de: Anglo-Nordic 290-FM [Radio] ID = 1533892 933x546
Select picture or schematic to display from thumbnails on the right and click for download.
For model Anglo-Nordic 290-FM bafle tiro tejido, Anglo Española de Electricidad S.A. (AEESA)

Country:  Spain
Manufacturer / Brand:  Anglo Española de Electricidad S.A. (AEESA)
alternative name

Sdad. Anglo Esp. de El. || Sociedad Anglo
Brand
AEESA
Year: 1964 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCC85 UCH81 UF89 UABC80 UL84
Semiconductors (the count is only for transistors) Selenium-Rectifier
Main principle Superheterodyne (common)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 125; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 14 cm = 5.5 inch
Power out
from Radiomuseum.org Model: Anglo-Nordic 290-FM [bafle tiro tejido] - Anglo Española de Electricidad
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 465 x 190 x 175 mm / 18.3 x 7.5 x 6.9 inch
Notes

Rectificador de Selenio.

Véase también el modelo 290-FM con rejilla madera.

Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 3'482.10 ESP

Model page created by Jose Luis Espinosa Gonzalez. See "Data change" for further contributors.
