Ansalorenz RIA 44

Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 945498) Radio
Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 1133364) Radio Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 1133366) Radio
Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 1133363) Radio Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 1133365) Radio
Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 2271168) Radio
Use red slider bar for more.
Ansalorenz RIA 44; Ansaldo-Lorenz, SRI, (ID = 1133364) Radio
Ansaldo-Lorenz, SRI,: Ansalorenz RIA 44 [Radio] ID = 1133364 500x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ansalorenz RIA 44, Ansaldo-Lorenz, SRI, ALI, Invictus; Genova/Milano

Country:  Italy
Manufacturer / Brand:  Ansaldo-Lorenz, SRI, ALI, Invictus; Genova/Milano
alternative name

Radio Invictus || SRI (Società Radio Italia)
Year: 1930/1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: E442 E415 B443 506
schematic requested
Main principle TRF with regeneration
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 115-220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Ansalorenz RIA 44 - Ansaldo-Lorenz, SRI, ALI,
Material Metal case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 450 x 200 x 200 mm / 17.7 x 7.9 x 7.9 inch
Notes

Vedi anche Ansalorenz S.R.T. 44 e Ansalorenz S.R.I. 44.

Price in first year of sale 1'550.00 LIT
Mentioned in -- Original prospect or advert (La Radio per Tutti - gennaio 1931)
Literature/Schematics (1) -- Original prospect or advert (La Radio per tutti, 01.03.1930)

Model page created by Fabio Masetti. See "Data change" for further contributors.
