Klarinet AS 138

Klarinet AS 138; Aristona; Denmark (ID = 2147477) Radio
Klarinet AS 138; Aristona; Denmark (ID = 2147467) Radio Klarinet AS 138; Aristona; Denmark (ID = 2157493) Radio
Klarinet AS 138; Aristona; Denmark (ID = 2157496) Radio Klarinet AS 138; Aristona; Denmark (ID = 2157501) Radio
Klarinet AS 138; Aristona; Denmark (ID = 2157502) Radio Klarinet AS 138; Aristona; Denmark (ID = 2157505) Radio
Klarinet AS 138; Aristona; Denmark (ID = 2157508) Radio
Use red slider bar for more.
Klarinet AS 138; Aristona; Denmark (ID = 2147467) Radio
Aristona; Denmark: Klarinet AS 138 [Radio] ID = 2147467 1400x1141
Select picture or schematic to display from thumbnails on the right and click for download.
For model Klarinet AS 138, Aristona; Denmark

Country:  Denmark
Manufacturer / Brand:  Aristona; Denmark
Year: 1941/1942 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH4 UCH4 UBL1 UY1N UM34
Main principle Super-Heterodyne (Super in general); ZF/IF 441 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110V= 220V 240V Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Klarinet AS 138 - Aristona; Denmark
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 485 x 350 x 265 mm / 19.1 x 13.8 x 10.4 inch
Notes

Betrieb mit 127V Wechselspannung möglich mit zusätslichem Spartrafo, siehe Aufdruch auf dem Bild von der Rückwand.

Net weight (2.2 lb = 1 kg) 11 kg / 24 lb 3.7 oz (24.229 lb)

Model page created by Uwe Roose. See "Data change" for further contributors.
