For model SA4136A, Aristona (B); Brüssel

Country:  Belgium
Manufacturer / Brand:  Aristona (B); Brüssel
Year: 1959 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF85 EABC80 EM84 EL84 EZ80
Main principle Super-Heterodyne (Super in general); ZF/IF 452/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 145; 220 Volt
Loudspeaker 2 Loudspeakers / Ø 9 cm = 3.5 inch
Power out
from Radiomuseum.org Model: SA4136A - Aristona B; Brüssel
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 460 x 280 x 205 mm / 18.1 x 11 x 8.1 inch
Notes

A useable schematic can be found with model B4X82A from Philips.

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)

Model page created by Marijn Hoogmoed. See "Data change" for further contributors.
