Panart Cricket

Panart Cricket ; ART - Panart; Milano (ID = 805335) Radio
Panart Cricket ; ART - Panart; Milano (ID = 2105651) Radio
Use red slider bar for more.
Panart Cricket ; ART - Panart; Milano (ID = 2105651) Radio
ART - Panart; Milano: Panart Cricket [Radio] ID = 2105651 276x166
Select picture or schematic to display from thumbnails on the right and click for download.
For model Panart Cricket, ART - Panart; Milano:
cATALOGO ANIE 1960-61

Country:  Italy
Manufacturer / Brand:  ART - Panart; Milano
Brand

Depaphon
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: OC44 OC45 OC45 OC71 OC72 OC72
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: Panart Cricket - ART - Panart; Milano
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 140 x 87 x 41 mm / 5.5 x 3.4 x 1.6 inch
Notes Mobile in 3 colori.
Completo di borsa e auricolare.
Net weight (2.2 lb = 1 kg) 0.540 kg / 1 lb 3 oz (1.189 lb)
Price in first year of sale 21'000.00 ITL
Source of data Guida Pratica Transistor Radios
Mentioned in Catalogo ANIE (1960-61)
Literature/Schematics (1) -- Schematic (Schemario di Apparecchi a Transistori R. Rosati Edizioni C. E. L. I.)

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
