Robin TR802/FM

Robin TR802/FM; ART - Panart; Milano (ID = 915130) Radio

Robin TR802/FM; ART - Panart; Milano (ID = 915131) Radio

Robin TR802/FM; ART - Panart; Milano (ID = 945148) Radio
Robin TR802/FM; ART - Panart; Milano (ID = 915132) Radio Robin TR802/FM; ART - Panart; Milano (ID = 2212438) Radio
Robin TR802/FM; ART - Panart; Milano (ID = 2212439) Radio Robin TR802/FM; ART - Panart; Milano (ID = 2212440) Radio
Robin TR802/FM; ART - Panart; Milano (ID = 2212441) Radio
Use red slider bar for more.
Robin TR802/FM; ART - Panart; Milano (ID = 915132) Radio
ART - Panart; Milano: Robin TR802/FM [Radio] ID = 915132 872x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Robin TR802/FM, ART - Panart; Milano:
Schemario di Apparecchi Radio a Transistor Vol 1° Antonelliana

Country:  Italy
Manufacturer / Brand:  ART - Panart; Milano
Brand

Depaphon
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF114 AF115 AF116 AF116 AF116 OC75 OC75 OC74 OC74
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 9 / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.5 cm = 4.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Robin TR802/FM - ART - Panart; Milano
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 370 x 140 x 110 mm / 14.6 x 5.5 x 4.3 inch
Notes Mobile in legno con frontale plastico. Esiste anche marchiata Kendall's
Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Price in first year of sale 48'000.00 ITL
Literature/Schematics (1) annuario ANIE 1963

Model page created by Enrico Bonisolo. See "Data change" for further contributors.
