833L

833L; Asa, Turku (ID = 1294942) Radio 833L; Asa, Turku (ID = 1336474) Radio
833L; Asa, Turku (ID = 1336475) Radio 833L; Asa, Turku (ID = 1336476) Radio
833L; Asa, Turku (ID = 1336477) Radio 833L; Asa, Turku (ID = 1336478) Radio
833L; Asa, Turku (ID = 1336479) Radio 833L; Asa, Turku (ID = 1336480) Radio
833L; Asa, Turku (ID = 1336481) Radio 833L; Asa, Turku (ID = 1361308) Radio
Use red slider bar for more.
833L; Asa, Turku (ID = 1294942) Radio
Asa, Turku: 833L [Radio] ID = 1294942 922x692
Select picture or schematic to display from thumbnails on the right and click for download.
For model 833L, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1956 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EC92 EC92 ECH81 EF85 EM34 EABC80 EL84
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: 833L - Asa, Turku
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 520 x 365 x 325 mm / 20.5 x 14.4 x 12.8 inch
Notes Record player: Cosmos 3-speed.

Model page created by Timo Rantasaari. See "Data change" for further contributors.
