843L

843L; Asa, Turku (ID = 233051) Radio 843L; Asa, Turku (ID = 233054) Radio
843L; Asa, Turku (ID = 233063) Radio 843L; Asa, Turku (ID = 233049) Radio
843L; Asa, Turku (ID = 233048) Radio 843L; Asa, Turku (ID = 233050) Radio
843L; Asa, Turku (ID = 233055) Radio 843L; Asa, Turku (ID = 233056) Radio
843L; Asa, Turku (ID = 1956893) Radio 843L; Asa, Turku (ID = 1956894) Radio
Use red slider bar for more.
843L; Asa, Turku (ID = 233051) Radio
Asa, Turku: 843L [Radio] ID = 233051 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model 843L, Asa, Turku

Country:  Finland
Manufacturer / Brand:  Asa, Turku
Year: 1957 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EC92 EC92 ECH81 EF85 EM34 EABC80 EL84
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: 843L - Asa, Turku
Material Wooden case
Dimensions (WHD) 460 x 304 x 295 mm / 18.1 x 12 x 11.6 inch
Notes ASA 843L has built in a Cosmos recordplayer with Ronette SA-250 pickup and dual side needle for 33/45/78 rpm records. Cosmos was an own brand of Asa Radio Oy.
Net weight (2.2 lb = 1 kg) 12.7 kg / 27 lb 15.6 oz (27.974 lb)
Source of data - - Data from my own collection

Model page created by Jari Aalto. See "Data change" for further contributors.
