AC Electric Model 40

Atwater Kent (Brand), C & A Odlin & Co. Ltd; Wellington

Data
Forum
Pictures
Collections

  • Year
  • 1928
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 355519

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • TRF with regeneration
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Alternating Current supply (AC) / 50Hz, 230 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AC Electric Model 40 - Atwater Kent Brand, C & A
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 432 x 191 x 254 mm / 17 x 7.5 x 10 inch
  • Notes

  • Atwater Kent Model 40 AC Electric

    The first Atwater Kent model to use a dynamic speaker and built-in power supply.

    Export version of the US Model 9800 Model 40 (A.C.)

    Distributed in New Zealand by C. & A. Odlin Co. Ltd.

    Made in the USA.

  • Net weight (2.2 lb = 1 kg)
  • 18 kg / 39 lb 10.4 oz (39.648 lb)
  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
