• Country
• Denmark

• Manufacturer / Brand
• Audiola, Nordisk Solar Industri A/S; Kolding

• Year
• 1954

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216337

• Number of Tubes
• 5

• Valves / Tubes
• UCH42 UAF42 UAF42 UL41 UY41

• Main principle
• Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• AC/DC-set / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 4 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Standard US 543 [1954] - Audiola, Nordisk Solar

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 390 x 230 x 200 mm / 15.4 x 9.1 x 7.9 inch

• Notes
• Sept. 1st 1954 manufacturing date (cabinet stamp) proven.

• Net weight (2.2 lb = 1 kg)
• 7 kg / 15 lb 6.7 oz (15.419 lb)

• Author
• Model page created by Mihály Horn. See "Data change" for further contributors.

• Other Models

• Here you find 20 models, 19 with images and 6 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Audiola, Nordisk Solar Industri A/S; Kolding
