Hotpoint-Bandmaster C26SE

Hotpoint-Bandmaster C26SE; Australian General (ID = 802164) Radio

Hotpoint-Bandmaster C26SE; Australian General (ID = 802165) Radio
Use red slider bar for more.
Hotpoint-Bandmaster C26SE; Australian General (ID = 802164) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1946 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6U7G 6J8G 6U7G 6G8G 6V6GT 5Y3GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 200-230; 230-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Hotpoint-Bandmaster C26SE - Australian General Electric GE
Material Wooden case
Shape Console, Lowboy (legs < 50 %).
Notes This model has seven bands giving continuous coverage from 550 kHz to 22.3 MHz. It uses the same chassis as the AWA Radiola model 707C.
Circuit diagram reference Australian Official Radio Service Manual Vol. V
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
