Hotpoint-Bandmaster M58SE

Country:  Australia
Manufacturer / Brand:  Australian General Electric (GE Company Australia Ltd., Associated, AGE, Bandmaster, Hotpoint), Sydney
alternative name

General Electric Company of Australia Ltd.
Year: 1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 6U7G 6J8G 6U7G 6SQ7GT 6U5 6SJ7GT 6V6GT 6V6GT 5Y3GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 200-230; 230-260 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 7 inch = 17.8 cm
Power out
from Radiomuseum.org Model: Hotpoint-Bandmaster M58SE - Australian General Electric GE
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes This model has seven bands, covering 540 kHz to 22.3 MHz with no gaps. It uses the same chassis as the AWA Radiola model 611T.
Price in first year of sale 64.00 Aus£
Circuit diagram reference Australian Official Radio Service Manual Vol. VI
Literature/Schematics (1) Mingay's Radio Diagram & I.F. Index

Model page created by Stuart Irwin. See "Data change" for further contributors.
