All Transistor Home Super 6511

Autocrat Radio Ltd.; Auckland

  • Year
  • 1960
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 345484

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Dry Batteries / D: 4 x 1.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
  • Power out
  • 0.16 W (0.21 W max.)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: All Transistor Home Super 6511 - Autocrat Radio Ltd.; Auckland
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Notes
  • 6 Transistor broadcast (MW) portable battery radio available in a range of pastel colours.

    Economical in operation running approx. 1000 hours on 4 flashlight batteries.

  • Price in first year of sale
  • 26.75 NZ £
  • Mentioned in
  • -- Original prospect or advert (Press 30 November 1960 Page 5)
  • Author
  • Model page created by Brian Stevens. See "Data change" for further contributors.
