Gandria var 2; Autophon AG inkl. (ID = 2076307) Radio

Gandria var 2; Autophon AG inkl. (ID = 2076308) Radio

Gandria var 2; Autophon AG inkl. (ID = 2076309) Radio

Gandria var 2; Autophon AG inkl. (ID = 2076310) Radio

Gandria var 2; Autophon AG inkl. (ID = 2076311) Radio

Gandria var 2; Autophon AG inkl. (ID = 2088602) Radio

Gandria var 2; Autophon AG inkl. (ID = 2088603) Radio
Gandria var 2; Autophon AG inkl. (ID = 726822) Radio Gandria var 2; Autophon AG inkl. (ID = 726824) Radio
Gandria var 2; Autophon AG inkl. (ID = 726823) Radio Gandria var 2; Autophon AG inkl. (ID = 709337) Radio
Use red slider bar for more.
Gandria var 2; Autophon AG inkl. (ID = 726822) Radio
Autophon AG inkl.: Gandria var 2 [Radio] ID = 726822 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gandria var 2, Autophon AG (inkl. Téléphonie SA); Solothurn

Country:  Switzerland
Manufacturer / Brand:  Autophon AG (inkl. Téléphonie SA); Solothurn
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH42 EAF42 EAF42 EL41 EZ40
Main principle Superheterodyne (common); ZF/IF 471 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: Gandria var 2 - Autophon AG inkl. Téléphonie
Material Bakelite case
Dimensions (WHD) 310 x 200 x 165 mm / 12.2 x 7.9 x 6.5 inch
Notes 500/20642*Geh.wie Mod.641,Sonderausf. 110-250Volt
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 395.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
