Beocenter 2200 2421
Bang & Olufsen B&O;: Beocenter 2200 2421 [Radio] ID = 1489963 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
Brand
|
B&O | ||||
|---|---|---|---|---|---|
| Year: 1985/1986 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | Semiconductors present. | ||||
| schematic requested | |||||
| Main principle | Super-Heterodyne (Super in general) |
|---|---|
| Wave bands | Broadcast, Long Wave and FM or UHF. |
| Details | Record Player (not changer) |
| Power type and voltage | Alternating Current supply (AC) / 220 Volt |
| Loudspeaker | - This model requires external speaker(s). |
| Power out | 25 W (undistorted) |
| from Radiomuseum.org | Model: Beocenter 2200 2421 - Bang & Olufsen B&O; Struer |
| Material | Modern plastics (no Bakelite or Catalin) |
| Shape | Tablemodel, with any shape - general. |
| Dimensions (WHD) | 740 x 95 x 325 mm / 29.1 x 3.7 x 12.8 inch |
| Net weight (2.2 lb = 1 kg) | 11 kg / 24 lb 3.7 oz (24.229 lb) |
Model page created by Igor Miler. See "Data change" for further contributors.
