Beocenter 4000 1603

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136922) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136923) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136925) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136926) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136927) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136928) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136929) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136930) Radio

Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136931) Radio
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507344) Radio Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1136918) Radio
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507343) Radio Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507347) Radio
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507348) Radio Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507349) Radio
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507350) Radio Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507352) Radio
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507353) Radio Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1595354) Radio
Use red slider bar for more.
Beocenter 4000 1603; Bang & Olufsen B&O; (ID = 1507344) Radio
Bang & Olufsen B&O;: Beocenter 4000 1603 [Radio] ID = 1507344 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Beocenter 4000 1603, Bang & Olufsen (B&O); Struer

Country:  Denmark
Manufacturer / Brand:  Bang & Olufsen (B&O); Struer
Brand

B&O
Year: 1978 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 80 W (unknown quality)
from Radiomuseum.org Model: Beocenter 4000 1603 - Bang & Olufsen B&O; Struer
Material Various materials
Shape Book-shelf unit.
Dimensions (WHD) 655 x 85 x 310 mm / 25.8 x 3.3 x 12.2 inch
Notes Entspricht technisch dem Beomaster 2200 Type 1601, jedoch mit eingebautem Tapedeck. Dieses ist vom Beocord 5000 Type 4705 abgeleitet, jedoch mit zwei Schwungmassen, aber nur einer Capstanwelle. Aufbau in Modulbauweise, die einzelnen Module stecken auf einem gemeinsamen Kunststoffboden, die Verbindungen sind in wire- wrap- Technik ausgeführt
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)
Source of data -- Original-techn. papers.
Mentioned in Funkschau (22/1978, S. 1071)

Model page created by Fritz Czapek † 29.9.17. See "Data change" for further contributors.
