Beolab 1700

Beolab 1700; Bang & Olufsen B&O; (ID = 1838618) Ampl/Mixer
Beolab 1700; Bang & Olufsen B&O; (ID = 1296726) Ampl/Mixer Beolab 1700; Bang & Olufsen B&O; (ID = 1062164) Ampl/Mixer
Beolab 1700; Bang & Olufsen B&O; (ID = 1296727) Ampl/Mixer Beolab 1700; Bang & Olufsen B&O; (ID = 1296728) Ampl/Mixer
Beolab 1700; Bang & Olufsen B&O; (ID = 1296729) Ampl/Mixer Beolab 1700; Bang & Olufsen B&O; (ID = 1296730) Ampl/Mixer
Beolab 1700; Bang & Olufsen B&O; (ID = 1297885) Ampl/Mixer Beolab 1700; Bang & Olufsen B&O; (ID = 1297886) Ampl/Mixer
Beolab 1700; Bang & Olufsen B&O; (ID = 1297887) Ampl/Mixer Beolab 1700; Bang & Olufsen B&O; (ID = 1297888) Ampl/Mixer
Use red slider bar for more.
Beolab 1700; Bang & Olufsen B&O; (ID = 1296726) Ampl/Mixer
Bang & Olufsen B&O;: Beolab 1700 [Ampl/Mixer] ID = 1296726 930x224
Select picture or schematic to display from thumbnails on the right and click for download.
For model Beolab 1700, Bang & Olufsen (B&O); Struer

Country:  Denmark
Manufacturer / Brand:  Bang & Olufsen (B&O); Struer
Brand

B&O
Year: 1973 ?? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 40 W (max.)
from Radiomuseum.org Model: Beolab 1700 - Bang & Olufsen B&O; Struer
Material Various materials
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 75 x 230 mm / 19.7 x 3 x 9.1 inch
Notes

Das Bild aus dem Verkaufprospekt zeigt die Kombination aus Verstärker (Beolab 1700) und Tuner (Beomaster 1700).

Stereo power amplifier 20 + 20 W RMS. Italian GBC advertising shows "Ambiofonico".

Ambiophony: Artificial reverberation in music reproduction. (Wikipedia).

Frequency response: 20 to 30,000 Hz.

Total harmonic distortion: 0.5 % at 1 kHz. Noise to signal ratio: 55 dB.

Source of data -- Original-techn. papers.
Mentioned in -- Original prospect or advert (Rivista Sperimentare dicembre 1975)

Model page created by Fritz Czapek † 29.9.17. See "Data change" for further contributors.
