Beolit 600 TR52

Beolit 600 TR52; Bang & Olufsen B&O; (ID = 443268) Radio

Beolit 600 TR52; Bang & Olufsen B&O; (ID = 443270) Radio
Beolit 600 TR52; Bang & Olufsen B&O; (ID = 443259) Radio Beolit 600 TR52; Bang & Olufsen B&O; (ID = 996549) Radio
Beolit 600 TR52; Bang & Olufsen B&O; (ID = 996550) Radio
Use red slider bar for more.
Beolit 600 TR52; Bang & Olufsen B&O; (ID = 443259) Radio
Bang & Olufsen B&O;: Beolit 600 TR52 [Radio] ID = 443259 933x539
Select picture or schematic to display from thumbnails on the right and click for download.
For model Beolit 600 TR52, Bang & Olufsen (B&O); Struer:
My Danish built Bang and Olufsen Beolit 600 type TR 52 LW/MW/VHF/Marine Band 9 transistor portable radio which has a circuit diagram inside dated 11/64.

Country:  Denmark
Manufacturer / Brand:  Bang & Olufsen (B&O); Struer
Brand

B&O
Year: 1964 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common); ZF/IF 444/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Beolit 600 TR52 - Bang & Olufsen B&O; Struer
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 205 x 105 mm / 12.4 x 8.1 x 4.1 inch
Notes Transistors: AF102, AF115, 3x AF116, 2x AC126, 2x AC128. Shortwave Marine Band 1.5-4.0 MHz. FM 88-100 MHz. Elliptical loudspeaker 180x120mm. Tuning meter.
Source of data - - Data from my own collection
