Beomaster 4500

Bang & Olufsen (B&O); Struer

Data
Forum
Pictures
Collections

  • Year
  • 1988–1994
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 163374
    • Brand: B&O

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • ZF/IF 455 kHz
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 110 W (unknown quality)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Beomaster 4500 - Bang & Olufsen B&O; Struer
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 620 x 70 x 250 mm / 24.4 x 2.8 x 9.8 inch
  • Notes
  • 5 Ausführungen:
    2961 Europa, LW 150 - 350 kHz
    2962 Europa, LW 150 - 350 kHz
    2963 USA & Canada
    2965 Australien
    alle mit FM 87,5 - 108,5 MHz
    2964 Japan mit FM 76 - 90 MHZ
    Output: 2* 20W bei 20-20000Hz, max. 2* 55W. Pre-set for 20 radio stations.
  • Price in first year of sale
  • 429.00 £
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Heribert Jung. See "Data change" for further contributors.
